Condition |
Brand New
|
Product Numbers |
Part Code: H810M GAMING WIFI6
EAN Number:
|
Stock Status |
| We have more stock arriving: 17/04/2025 |
Delivery Price |
Add to Cart for Instant Delivery Pricing |
Quantity Price Break Discounts |
| 5 - 9 units |
£98.46 exc vat |
| 10 - 19 units |
£98.22 exc vat |
| 20 - 49 units |
£97.97 exc vat |
| 50 - 99 units |
£97.72 exc vat |
| 100 or more units |
* Negotiable * |
Discounts Are Applied During Checkout |
Share Content |
|
|
Product Title: +NEW+Gigabyte H410M H V2 (Socket 1851//H810/DDR5/S-ATA 6Gb/s/Micro ATX)
KSN SKU Code: MB126737
Manufacturers Part Code: H810M GAMING WIFI6
Product Name: +NEW+Gigabyte H410M H V2 (Socket 1851//H810/DDR5/S-ATA 6Gb/s/Micro ATX)
Web Address: www.gigabyte.com
Model Number: H810M GAMING WIFI6
EAN: 4719331869090
Package Type: Retail
Warranty: 3 Years
BIOS: 1 x 256 Mbit flash‚Use of licensed AMI UEFI BIOS‚PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset: Intel H810 Express
CPU Interface: Socket 1851
CPU Support: https://www.gigabyte.com/Motherboard/H810M-GAMING-WIFI6/support#support-cpu
RAM Technology: DDR5 (Dual Channel)
RAM Slots: 2 x 288-pin
RAM Speeds: Up to DDR5 6400
Max. Memory Support: 128GB
PCI Express 4.0 x16: 1
PCI Express 3.0 x1: 1
S-ATA 6Gb/s Port(s): 4
RAID: Raid 0/1/5/10
M.2 Socket(s): 1
LAN Speed: Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless NIC: Wi-Fi 6
Wireless Technology: WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands
Bluetooth: v5.3
On-Board Audio: Realtek Audio CODEC‚High Definition Audio‚2/4/5.1/7.1-channel
On-Board Video: Processor with integrated graphics is required
Back PS/2 Keyboard/Mouse Port: 1
Back USB 2.0 Port(s): 5
Back USB 3.2 Port(s) Type-A Gen 1: 1
Back HDMI Port(s): 1
Back DisplayPort(s): 1
Back LAN Port(s): 1
Back Audio Jack(s): 3
24-pin ATX Power: 1
8-pin ATX Power: 1
USB 2.0 Header(s): 2
USB 3.2 Header(s) Gen 1: 2
COM Port Header(s): 1
Front Panel Audio Connector: 1
TPM Header(s): 1
S/PDIF Out Header(s): 1
Internal Other Port(s): 2 x addressable RGB Gen2 LED strip headers
Form Factor: Micro ATX
Product Width: 215mm
Product Length: 244mm
Special Features: Supports Intel Core Ultra processors (Series 2).‚WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation.‚EZ-Latch: PCIe x16 Slot with Quick Release Design.‚M.2 EZ-Latch Plus: Screwless installation for M.2 SSDs.‚Friendly UI: Multi-Theme, and Q-Flash Auto Scan in BIOS and SW.‚Ultra-Fast Storage: PCIe 4.0 x4 M.2 slots.‚Efficient Thermal: VRM Thermal Armor Advanced and M.2 Thermal Guard.‚Fast Networking: 2.5GbE LAN and Wi-Fi 6 802.11ax.‚Extended Connectivity: HDMI, DisplayPort.
Package Contents: Motherboard‚Manual‚Quick Installation Guide‚1 x Antenna‚2 x SATA cables‚Pack of M.2 thick/thin rubber pads
Keywords: Motherboard‚1851‚H810‚DDR5‚HDMI‚DisplayPort‚Micro ATX
|
